Description

Computerized Vickers Hardness tester has a C type load frame. The job is positioned on the test table and lifted by the hand wheel to set focal point. Required load is applied on the job and removed by motorized system. After indexing the plate , optics will come in place of indentation & will transfer the image of indentation to Camera. The image is further digitalized and processed by PC/ TPC for measurement. The diagonal / diameter of the image can be measured automatically / semi automatically / manually to get Vickers Hardness value.

Application

Features

• Fully computerized system for indentation measurement and display.
• Accurate measurement of Vickers Hardness through matched Optics, CCD Camera, hardware and software using advanced image processing technologies.
• Wide range of testing
• High accuracy & confirms to related to IS & ISO standard
• Windows based software system.
• Three modes of measurement, manual, semi auto and auto
• In auto mode the image is scanned for measurement and hardness is displayed automatically.
• In Semi automatic mode curser is to click on the indentation to get the hardness value.
• In manual mode curser is to be matched to the diagonal / diameter of the indentation to get the

Specifications

Accessories

• Flat Table of 100mm Dia
• Vee Table for Specimen- 6 to 80 mm Dia
• Vickers Diamond Indenter
• Vickers test block
• Electrical Cord
• Instruction Manual

Software Description

Download Cataloge

Click Here For Brochure

Description

Application

Features

• Table Top sturdy Model
• Front projection screen with Micrometer with Optical system List Count of 0.0005 mm
• Motorised Loading & Unloading of Loads
• Load selection By Indexible Load Selection Knob
• Very wide testing range from very soft Metals to Very Hard Metals
• Models with minimum 1 Kg Load are available
• The illumination light goes off during the application of Load which reduces the operator's fatigue due to continuous light illumination as well as increases Bulb life
• State of Art Load Damping system for a very smooth & Jerk free Loading & unloading of applied Load
• Machine Confirms to IS: 1754-2002 for Vickers & IS: 2281-2005 / BS240 for Brinell.

Specifications

Accessories

• Flat Table of 100mm Dia
• Vee Table for Specimen: 6 to 80 mm Dia
• Vickers Diamond Indenter
• Vickers test block
• Electrical Cord
• Instruction Manual

Software Description

Download Cataloge

Click Here For Brochure

Description

• Automatic loading - dwell - unloading
• Precise manual analog eyepiece 10X
• Reserved CCD camera path, can work with camera and hardness software system
• High resolution optical system, indentation image very clear
• One time casting shell with car painting
• Touch screen with menu structure, easy operate
• LED light source, service time more longer

Application

• Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
• Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
• Glass, chip and ceramic material.

Features

• The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
• According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
• With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
• Large size touch screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process.
• Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Accessories

• 10X analog eyepiece : 1 pc
• Power line : 1 pc
• 10X and 20X objective lens : 1 pc
• Dust proof cover : 1 pc
• Vickers indenter : 1 pc
• Hardness Conversion Tables : 1 pc
• Level bubble : 1 pc
• Quality certificate : 1 pc
• Large / Medium / V-shape Testing Table : 1 pc
• Warranty Card : 1 pc
• horizontal adjusting screw : 4 pcs
• Standard block of hardness : 2 pcs
• Accessory case : 1 pc
• Manual Book : 1 pc

Optional Purchase Accessories:

• Image analysis software
• Metallographic equipment
• Knoop Indenter
• hardness block
• 15X micrometer eyepiece

Software Description

Software support automatic measurement & manual measurement, can generate test report automatically in word/Excel format, including hardness value, test force, indentation image and hardness curve, etc.

Software can control the machine turret and generate test report including hardness value curve (Via RS232 port). Software install on the computer, connect with hardness tester through RS232 port. All the testing result can save to computer and generate test report in word format.

Download Cataloge

Click Here For Brochure

Description

• Automatic loading - dwell - unloading
• Precise manual analog eyepiece 10X
• Reserved CCD camera path, can work with camera and hardness software system
• High resolution optical system, indentation image very clear
• One time casting shell with car painting
• Touch screen with menu structure, easy operate
• LED light source, service time more longer

Application

• Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
• Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
• Glass, chip and ceramic material.

Features

• The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
• According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
• With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
• Large size touch screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process.
• Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Accessories

• 10X analog eyepiece : 1 pc
• Power line : 1 pc
• 10X and 20X objective lens : 1 pc
• Dust proof cover : 1 pc
• Vickers indenter : 1 pc
• Hardness Conversion Tables : 1 pc
• Level bubble : 1 pc
• Quality certificate : 1 pc
• Large / Medium / V-shape Testing Table : 1 pc
• Warranty Card : 1 pc
• horizontal adjusting screw : 4 pcs
• Standard block of hardness : 2 pcs
• Accessory case : 1 pc
• Manual Book : 1 pc

Optional Purchase Accessories:

• Image analysis software
• Metallographic equipment
• Knoop Indenter
• hardness block
• 15X micrometer eyepiece

Software Description

Software support automatic measurement & manual measurement, can generate test report automatically in word/Excel format, including hardness value, test force, indentation image and hardness curve, etc.

Software can control the machine turret and generate test report including hardness value curve (Via RS232 port). Software install on the computer, connect with hardness tester through RS232 port. All the testing result can save to computer and generate test report in word format.

Download Cataloge

Click Here For Brochure

Description

• Automatic loading - dwell - unloading
• Precise manual analog eyepiece 10X
• Reserved CCD camera path, can work with camera and hardness software system
• High resolution optical system, indentation image very clear
• One time casting shell with car painting
• Touch screen with menu structure, easy operate
• LED light source, service time more longer

Application

• Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
• Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
• Glass, chip and ceramic material.

Features

• The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
• According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
• With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
• Large size touch screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process.
• Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Accessories

• 10X analog eyepiece : 1 pc
• Power line : 1 pc
• 10X and 20X objective lens : 1 pc
• Dust proof cover : 1 pc
• Vickers indenter : 1 pc
• Hardness Conversion Tables : 1 pc
• Level bubble : 1 pc
• Quality certificate : 1 pc
• Large / Medium / V-shape Testing Table : 1 pc
• Warranty Card : 1 pc
• horizontal adjusting screw : 4 pcs
• Standard block of hardness : 2 pcs
• Accessory case : 1 pc
• Manual Book : 1 pc

Optional Purchase Accessories:

• Image analysis software
• Metallographic equipment
• Knoop Indenter
• hardness block
• 15X micrometer eyepiece

Software Description

Software support automatic measurement & manual measurement, can generate test report automatically in word/Excel format, including hardness value, test force, indentation image and hardness curve, etc.

Software can control the machine turret and generate test report including hardness value curve (Via RS232 port). Software install on the computer, connect with hardness tester through RS232 port. All the testing result can save to computer and generate test report in word format.

Download Cataloge

Click Here For Brochure

Description

Application

• Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
• Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
• Glass, chip and ceramic material.

Features

• The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
• According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
• With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
• Industrial digital screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process;
• Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Accessories

• 10X electronic eyepiece : 1pc
• 10X and 20X objective lens : 1pc
• Vickers indenter : 1pc
• Level bubble : 1pc
• Large / Medium / V-shape Testing Table : 1pc
• Power line : 1pc
• Dust proof cover : 1pc
• Manual Book : 1pc
• Hardness Conversion Tables : 1pc
• Quality certificate : 1pc
• Warranty Card : 1pc
• Accessory case : 1pc
• Standard block of hardness : 2pcs
• horizontal adjusting screw : 4pcs

Software Description

Download Cataloge

Click Here For Brochure

Description

Application

• Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
• Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
• Glass, chip and ceramic material.

Features

• The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
• According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
• With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
• Industrial digital screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process;
• Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Accessories

• 10X electronic eyepiece : 1pc
• 10X and 20X objective lens : 1pc
• Vickers indenter : 1pc
• Level bubble : 1pc
• Large / Medium / V-shape Testing Table : 1pc
• Power line : 1pc
• Dust proof cover : 1pc
• Manual Book : 1pc
• Hardness Conversion Tables : 1pc
• Quality certificate : 1pc
• Warranty Card : 1pc
• Accessory case : 1pc
• Standard block of hardness : 2pcs
• horizontal adjusting screw : 4pcs

Software Description

Download Cataloge

Click Here For Brochure
