BTM-50
Tool Maker Microscope
Description
Our BTM-50 Industrial Measuring Microscope supports a wide range of application from industrial of optics, machines, electronics, precision measurement of geometric dimension, specially measuring from in machine cutter family program
Application
Features
Specifications
| Model No. | BTM-50 | |
| Type | Monocular Inclined at 30 deg. | |
| Eyepiece | 15x | |
| Objective | 2x | |
| XY Table Travel | 50x50mm | |
| Graduation | 0.002mm (0.0001) | |
| Minimum Angle reading | 6´ | |
| Rotation | 360 | |
| Table Top Size | 150x150mm | |
| Traverse | 50mmx50mm | |
| Measurement | Micrometer Heads | |
| Readout | Direct | |
| Glass stage | Dia 70mm | |
| Workstage | Transmitted Light Halogen Bulb with Filter reflected Light | |
| Illumination Controls | On/Off Switch. Intensity Controllers for Transmitted & reflected Light | |
| Power Input | AC 220V - 240V, 50Hz. Single Phase | |
| Furnished Accessories | Power supply cord, Vinyl cover, Fuse bulb | |
| Optional Accessories | Rotary Tables | |
| 5x, 10x Objective | ||
| Digital Display Micrometer Heads | ||
Accessories
Software Description
Download Cataloge
ENQUIRY
BTM-50
Tool Maker Microscope
Tool Maker Microscope
TM-50
Tool Maker Microscope
Description
Our TM-50 Tool Makers Microscope designed as per international standards and offers wide range of application which include dimensional, angle and contour measurements of miniature parts as well as inspection of mechanical surfaces, Erect Image, Observation Tube - Monocular inclined at 300.It is an ideal measuring instrument for simplifying inspection and precision measurement of diameter, forming tools, gauges as well as temples checking of thread and angles.
Application
Features
Specifications
| Model No | TM-50 |
| Magnification | 30x (Standard) |
| Objective | 2x Achromatic |
| Eyepiece | WF 15x with Cross reticule |
| Objective Tube | Monocular inclined at 30 |
| Eyepiece Protector | Graduated 0 to 360 with adjustable Vernier reading to 6 min. Cross reticule incorporated in the protector Head rotating in the optical axis of the microscope. |
| Measuring Stage | 152mm x152mm size assembled on ball bearing guides to provide accurate and smooth stage stroke upto 50mm in each direction with the use of gauge blocks. |
| Micro Head | Standard Micro Head 0-25mm, least count 0.01mm. |
| Illumination | SUB-STAGE LAMP emits transmitted light from bottom source equipped with collimated green filterHalogen light. OBLIQUE ILLUMINATORS with relief structure are also provided. |
| Dimensions/Weight | 450x300x400mm/16kgs. |
| Complete Microscope is supplied in Wooden storing Cabinet with vinyl cover, spare bulb cord, gauge Blocks and operating Manual | |
Accessories
Software Description
Download Cataloge
ENQUIRY
TM-50
Tool Maker Microscope
Tool Maker Microscope
BATM-14B
Advance Digital Toolmaker Microscope with Data Processor
Description
Our BATM-14B Tool Makers Microscope designed as per international standards and offers wide range of application.
- Adopts photoelectric display technology, takes high precision grating scale as measuring units for X and Y axis, Digital Read Out shows data directly, convenient to do measurement.
- It provides various eyepieces and objectives to get a clear image and large view field.
- Main microscope can deflect left and right, suitable for the measurement of spiral parts.
- LED illuminating lighting for transmission and reflecting with low heating dissipation and long life.
- High speed movement and micro motion devices could realize quick switch.
- Equipped with tailstock rack to measure shaft parts.
- Variety of accessories are provided to achieve extensive uses.
Application
Features
Specifications
| Model No | BATM-14B |
| Worktable: Measuring range | |
| X- Coordinate | 150mm |
| Y- Coordinate | 75mm |
| Measuring resolution | 0.001mm |
| Accuracy of Instrument | (2+L/50) µm of which, L= measured Length (unit: |
| Diameter of Circular worktable | Ø 190mm (Glass), Ø280mm(metal) |
| Angular calibrated range of the circular worktable | 0°-360° |
| Measured angle resolution ratio of the circular | 3’ |
| Microscope upright column | |
| Deflection angle | ±12° |
| Calibrated value of the slope angle | 30’ |
| Goniometric eyepiece | |
| Angular calibrated range | 0°-360° |
| Angular calibrated value | 1’ |
| Template eyepiece | |
| Calibrated range | ±7° |
| Angular calibrated value | 10’ |
| Optical detector | |
| Minimum detective hole diameter | Ø5mm |
| Maximum detective depth | 15mm |
| Measuring force | 0.1N |
| Tailstock rack | |
| Maximum clamping diameter | Ø70mm |
| Maximum clamping length | Ø190mm |
| Load capacity of instrument | 20 kg |
