Description
ACO-50 Abrasive Cutting Machine is rugged, sturdy and designed to cut metallurgical samples to optimal quality consistently and safely. Cutting wheel mounted on the spindle to get the optimum output of the motor. The movement of cutting wheel towards the specimen is applied by handle fixed with motor base pivot spindle and the cutter unit is balanced by springs for smooth downward movement. It has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of heat. This machine features easy operation and reliable safety. It is the necessary specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Large viewing window to monitor the cutting operation.
- Inside chamber is illuminated and see-through hood is provided for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch
- Door Safety Interlock
- Side Opening for Longer Component.
- Easy Operator Panel
Specifications
| Model No. | ACO-50 |
| Cutting Action | By manual Cut-Off wheel Arcs down |
| Cutting Capacity | Upto 50mm |
| Cut-Off Wheel Size | 8” (200mm) ID: 31.5mm, Thickness: 1.5mm |
| Cutting motor Power | 2 HP, 3Phase 420 Volts, 50Hz |
| Abrasive Wheel RPM | 2800 RPM |
| Coolant Motor Power | 0.1 HP 3 Phase 2800 RPM |
| Coolant Tank | 25 Ltr. Recirculating Coolant tank inbuilt |
| Cooling | By High flow water jets to provide optimum cooling |
| Table movements | X axis –100mm Y axis—120mm |
| Vice | Self-Centering 360 rotation, Jaw Opening 2” |
| Safety Feature | Emergency Stop Switch with Door limit Switch |
| Light in the working area | Fluorescent light in the working area provides safe and clear illumination. |
| Dimensions | 600mm X 1000mm X 950mm (approx.) |
| Weight | 100 Kg. (approx.) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Manual Abrasive Cut Off Machine
Description
Our ACO-100 Metallographic specimen cutting machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure.
It has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of heat. This machine features easy operation and reliable safety. It is the necessary specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Large viewing window to monitor the cutting operation.
- Inside chamber is illuminated and see-through hood is provided for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch
- Door Safety Interlock
- Side Opening for Longer Component.
- Easy Operator Panel
Specifications
| Model No. | ACO-100 |
| Operation | Manual operation by moving motor to the sample. Sample can be moved by lead screw. |
| Cutting Action | By manual Cut-Off wheel Arcs down |
| Cutting Capacity | Upto 100mm |
| Cut-Off Wheel Size | 12” (300mm) |
| Cutting motor Power | 3HP, 3Phase 415 Volts, 50Hz |
| Abrasive Wheel RPM | 2800 RPM |
| Coolant Motor Power | 0.1 HP 3 Phase 2800 RPM |
| Coolant Tank | 50 Ltr. Recirculating Coolant tank inbuilt |
| Cooling | By High flow water jets to provide optimum cooling |
| Vice | Self-Centering 360 rotation, Jaw Opening 4” |
| Safety Feature | Emergency Stop Switch with Door limit Switch |
| Light in the working area | Fluorescent light in the working area provides safe and clear illumination. |
| Dimensions | 1500mm X 1150mm X 1780mm (approx.) |
| Weight | 400 Kg. (approx.) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Manual Abrasive Cut Off Machine
Description
Our ACO-150 Metallographic specimen cutting machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure.
It has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of heat. This machine features easy operation and reliable safety. It is the necessary specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Large viewing window to monitor the cutting operation.
- Inside chamber is illuminated and see-through hood is provided for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch
- Door Safety Interlock
- Side Opening for Longer Component.
- Easy Operator Panel
Specifications
| Model No. | ACO-150 |
| Operation | Manual / Automatic |
| Cutting Action | By manual Cut-Off wheel Arcs down |
| Cutting Capacity | Upto 150mm |
| Cut-Off Wheel Size | 16” (400mm) |
| Cutting motor Power | 5HP or 7.5HP (As per customer requirements) 3Phase 415 Volts, 50Hz |
| Abrasive Wheel RPM | 2400 RPM approx |
| Spindle RPM | 2400 RPM approx |
| Table Movement | X- Axis – 100mm Y- Axis – 120mm |
| Coolant Motor Power | 0.1 HP 3 Phase |
| Coolant Tank | 50 Ltr. Recirculating Coolant tank inbuilt |
| Cooling | By High flow water jets to provide optimum cooling |
| Vice | Self-Centering 360 rotation, Jaw Opening 6” |
| Safety Feature | Emergency Stop Switch with Door limit Switch |
| Dimensions | 1500mm X 1150mm X 1780mm (approx.) |
| Weight | 400 Kg. (approx.) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Manual/Automatic Abrasive Cut Off Machine
Description
Our ACO-200 Heavy Duty Metallographic Abrasive cut-off machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure. It has built in cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of heat.
ACO-200 Abrasive Cutter is rugged, sturdy and designed to cut metallurgical samples to optimal quality consistently and safely. Cutting wheel spindle is connected with motor shaft by pulley and belt mechanism.
The movement of cutting wheel towards the specimen is applied by handle fixed with motor base pivot spindle and the cutter unit is balanced by springs for smooth downward movement
Application
Features
- Heavy Duty Abrasive Cutting Machine
- Large viewing window to monitor the cutting operation.
- Illuminated Inside chamber for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch
- Door Safety Interlock
- Side Opening for Longer Component.
- Easy Operator Panel
Specifications
| Model No. | ACO-200 |
| Cutting Action | By manual Cut-Off wheel Arcs down (Automatic available on demand) |
| Cutting Capacity | Upto 200mm |
| Cut-Off Wheel Size | 20” (500mm) |
| Cutting motor Power | 15 HP, (Bharat Bijli) 3 Phase 440Volts, 50Hz |
| T Slot Bed | 450 X 450mm |
| Travel (XY) | 200x300mm |
| Coolant Motor Pump | 0.24 HP, 3 Phase (70LPM) |
| Coolant Tank | 100 Ltr. Recirculating Coolant tank inbuilt |
| Cooling | By 3 High flow water jets to provide optimum cooling |
| Vice | 8” Vice with T slot bed for clamping of components |
| Light in working area | Fluorescent light in the working area provides safe and clear illumination |
| Safety Feature | Emergency Stop Switch with Door limit Switch |
| Oscillation Shall Be Provided for Smooth Cutting | |
| Splash proof, corrosion resistant see-through hood | |
| Dimensions | 1100mm X 1650mm X 1970mm (approx.) |
| Weight | 1200 Kg. (approx.) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Manual/Automatic Heavy Duty Abrasive Cut Off Machine
Description
Automatic Metallographic Specimen cutting machine is equipped with big cutting room and movable T-shape work table. Therefore, this machine has the ability of cutting rectangle and large specimens. Also, it is equipped separate type vice is very convenient for operator to clamp various heterotypic work pieces. It is the ideal metallographic specimen preparation equipment to be used in factories, colleges and researching purpose.
Application
Features
- Large viewing window to monitor the cutting operation.
- Illuminated Inside chamber for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch
- Door Safety Interlock
- Easy Operator Panel
Specifications
| Model No. | BC-80B | BC-100B |
| Operation | Automatic | |
| Max. cutting diameter | Ø80mm | Ø100mm |
| Max. Cutting volume | 80mm x 200mm | 100mm x 200mm |
| Main shaft rotating speed | 2200 rpm | |
| Automatic cutting speed | 0.1 †3.0mm/min. (0.1mm/min. increment) | |
| Sand wheel specification | 350 x 2.5 x 32mm | 350 x 2.5 x 32mm |
| Worktable size | 320mm x 300mm | |
| Motor power | 3KW | |
| Power supply | 3â€phases, 380V, 50Hz | |
| Dimensions | 930 x 700 x 610mm | |
| Net weight | 220 KG | |
Accessories
Software Description
Download Cataloge
ENQUIRY
Automatic Abrasive Cut Off Machine
Description
BSQ-80 Metallographic specimen cutting machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure. It has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of superheat. This machine features easy operation and reliable safety. It is the necessary specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Large viewing window to monitor the cutting operation.
- Illuminated Inside chamber for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch
- Door Safety Interlock
- Easy Operator Panel
Specifications
| Model No. | BSQ-80 |
| Max. cutting diameter | Ø80mm |
| Rotating speed of main shaft | 2800 rpm |
| Sand wheel specification | 250 x 2 x 32mm |
| Vice | Quick clamping |
| Chamber Lighting | LED Lighting system |
| Motor | 2.2KW |
| Cooling | 60L water cooling tank |
| Cutting wheel | 200 x 1.0 x 32mm |
| Cutting power | 1100W |
| Power source | 220V 50HZ |
| Overall Dimension | 750 x 700 x 680mm |
| Weight | 125kg. Approx. |
Accessories
Software Description
Download Cataloge
ENQUIRY
Manual Abrasive Cut Off Machine
Description
Our BGE-100S Manual/Automatic Metallographic specimen cutting machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure. It has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of superheat. This machine has stainless steel machine body and worktable, and it features easy operation and reliable safety. It is the necessary specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Stainless steel machine body and worktable
- Equipped with water jet cleaning device
- 60L water cooling system
Specifications
| Model No. | BGE-100S |
| Max. cutting diameter | Ø100mm |
| Rotating speed of main shaft | 2200 rpm |
| Sand wheel specification | 350 x 2.5 x 32mm |
| Max. worktable movable distance | 300mm |
| Max. movable travel for automatic cutting | 145mm |
| Motor | 3.3 KW |
| Power supply | 380V, 50Hz (three phase) |
| Overall Dimension | 900 x 860 x 620mm |
| Weight | Approx. 272kg. |
Accessories
Software Description
Download Cataloge
ENQUIRY
Manual/Automatic Abrasive Cut Off Machine
Description
Our BETACUT-100 Metallographic Specimen Cutting Machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure. It is a kind of Manual/Automatic cutting machine and can be switched between Manual and Automatic modes as per user requirements.
The machine has large work table and long cutting length which make it possible to cut large samples. The main shaft of cutting disc can also move upward or downward which can prolong the using life of cutting disc greatly. The machine has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of superheat.
This machine features easy operation and reliable safety. It is the necessary specimen preparing instrument for usingin factories, scientific research institutes and laboratories of colleges
Application
Features
- Quick clamping vice.
- LED lighting system
- Main shaft of cutting disc is movable upward and downward which can prolong the using life of cutting disc greatly
- Two working modes of Intermittent cutting and continuous cutting
- 60L water coolant Tank
Specifications
| Model No. | BETACUT-100 |
| Max. cutting diameter | Ø100mm |
| Rotating speed of main shaft | 2300 rpm |
| Sand wheel specification | 350 x 2.5 x 32mm |
| Automatic feeding speed | 0-180mm/min |
| Cutting disc upward and downward moving distance | 0-50mm |
| Forward and backward moving distance | 0-340mm |
| Working table size | 430 x 400 mm |
| Motor power | 3 KW |
| Power supply | 380V, 50Hz (3-Phases) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Manual Abrasive Cut Off Machine
Description
Our BETACUT-5 Precise Cutting Machine can be used to cut non-metallic material, circuit board, semiconductor, super hard material etc. The cutting precision can reach 0.01mm.
The machine is equipped with many jigs, which make it possible to cut samples with irregular shape. It is an ideal precise cutting machine for the scientific research institutes and industrial enterprises.
Application
Features
- Closed-loop control, speed precise control. Speed range：200-1500 r /min
- Precise cutting, precision can reach 0.01mm
- Cutting disc applied widely, use Ultra-thin diamond grinding wheel to get better result
Specifications
| Model No. | BETACUT-5 |
| Grinding wheel | 150mm Ultra-thin cutting disc (12.7mm, hole) |
| Speed range | 200-1500 r/min |
| Dimension | 405Lx 405W x 330H mm |
| Motor power | 125W |
| Power supply | 220V, 50/60Hz |
| Weight | 30kg |
Accessories
- Single head jig
- Double head jig
- Irregular sample jig
- Long sample jig
- 32mm inset sample jig
- 40mm inset sample jig
- Water drop jig
- Electroplate diamond grinding wheel
- Power Cord
Software Description
Download Cataloge
ENQUIRY
Precise Abrasive Cut Off Machine
Description
Our BTQ-5000B Precise specimen Cutting Machine can be used to cut material, electronic element, electronic element, crystals, hard alloy, rock sample, core sample, concrete, organic materials, biological materials (teeth, bones), etc. It applies precise cutting without deformation.
The device features high-power servo motor driving, high locating accuracy, large range of speed, high cutting power, internal circulation cooling system, preinstall feed speed, menu control and liquid crystal display, etc. The users are free to define the cutting method. It is an ideal precise cutting machine which can be used in industrial and mining enterprises, scientific research institutes to prepare high quality samples.
Application
Features
Specifications
| Model No. | BTQ-5000B |
| Max cutting section | φ60mm |
| Feeding speed | 0~30mm/min (increment 0.01mm) |
| Speed | 300~5000rpm |
| Maximum stroke | Y axis 200mm |
| Cutting wheel | 200 x 1.0 x 32mm |
| Cutting power | 1100W |
| Power source | 220V 50HZ |
| Weight | Approx. 130 KG |
| Overall Dimension | 700mm×720mm×410mm |
Accessories
Software Description
Download Cataloge
ENQUIRY
Precise Abrasive Cut Off Machine
Description
BANBROS Model BC-50A Metallographic Specimen Precise Cutting Machine is very suitable for precise cutting of various metallographic hard samples. This machine can be equipped with diamond saw blade and other resin blade so as to meet the demands of cutting of various specimens. It features wide application, high cutting accuracy, powerful cutting ability and variable speed adjusting range. It is the necessary specimen preparing instrument for using in factories, scientific research institutes, laboratories and colleges etc.
Application
Features
- Built-in re-circulating cooling system with flexible and adjustable hoses.
- Easy operation and reliable safety, no programming need to be done.
- Touch screen panel for operation
- Variable Speed, Automatic feed and feed rate.
- Motorized positioning system
- Suitable to cut of various type of samples like metals, ceramics, composite materials, sintered carbides, crystals, thermal spray coatings, etc. precisely and without any deformation.
- All major parameters can easily monitored on touch screen panel.
- Automatic motorized cutting Action by Y movement
- Intelligent feed control for Over Load of the sample
- Pulse cutting to reduce heat of the hard material specimen
- Movable cutting large T-slot SS bed free from corrosion
- Horizontal X-movement facility up to 50mm available with automatic mode.
- 40mm height adjustment of cut-off wheels is available in vertical direction that can be set through graphical touch screen.
- Possible to pre-set the cutting length from 0 to maximum in steps of 1 mm
- Precise positioning of the job in steps of 0.5mm
- Closed cutting chamber with safety switch
- Illumination through water proof LED
- Availability of Emergency stop Switch with safety door interlocking system
Specifications
| Model No. | BC-50A |
| Mode of cutting | Automatic |
| Cutting capacity | 50 mm |
| Rotating speed adjustment | Variable 500-5000mm |
| Wheel Compatibility of size | 100(4”) -200mm (8”) |
| 100(4”) -200mm (8”) | 2 HP |
| Power supply | 230V, 50HZ, Single Phase, AC |
Accessories
Software Description
Download Cataloge
ENQUIRY
Metallographic Automatic High Speed Precision Cut-Off Machine
Description
Model BTQ-5A Low speed precise specimen cutting machine is suitable for the precise cutting of various hard materials. It is especially suitable for the precise cutting of all kinds of small metal, non-metal pieces and various electronic components.
This machine can be equipped with diamond saw blade and other resin blade so as to meet the demands of cutting of various specimens. Four specimen clamping grippers are equipped with this machine and it can realize the positioning cutting at best angle for the work pieces. It is equipped with positioning limit switch which can also help to realize work piece processing without being watched.
The main shaft features high running speed and the horizontal feeding position of the work piece being processed can be adjusted precisely. It is the ideal metallographic specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
Specifications
| Model No. | BTQ-5A |
| Movable stand travel | 25mm |
| Positioning accuracy | 0.01mm |
| Rotating speed of main shaft | 60-600 rpm adjustable |
| Diameter of blade | Ø100mm (Ø150mm optional) |
| Motor power | 100W |
| Power supply | Single phase, 220V, 50Hz |
| Dimensions | 35 x 31 x 21 cm |
| Weight | 19 Kg |
Accessories
Software Description
Download Cataloge
ENQUIRY
Low Speed Abrasive Cut Off Machine
Description
Our BANBROS BTQ-5T Low speed specimen cutting machine is suitable for the high precise cutting of various materials. It is especially suitable for the precise cutting of small metal, non-metal pieces, electronic components. This Table top model can be equipped with diamond saw blade so as to meet the demands of cutting of various specimens. It is equipped with positioning limit switch which can also help to realize work piece processing without being watched. It is the ideal metallographic specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Provision to Accommodate of different vice.
- Microchip Technology Operating System.
- Micrometer for cross-feed adjustment of 0-25 mm.
- Stainless Steel/Aluminium constructed body for corrosion resistant.
- Availability of an automatic limit switch, cut-off switch and safety emergency switch.
- Gravity feed system minimizing deformation of delicate parts.
- Programmable PLC Touch screen with human-machine interface for trouble free operation
- Touchpad to set RPM and ON/OFF.
- Horizontal feed position.
- Detachable built-in Re-circulation stainless steel coolant tray for easy cleaning and replacement of coolant
- Transparent coolant splash Guard
- Diamond cutting blade runs through the coolant to avoid heating of the sample.
- Low noise level suitable to trouble free operation.
Specifications
| TECHNICAL SPECIFICATIONS | BTQ-5T |
| Diameter of wheel (diamond) | 4” inch above 60 HRC |
| Arbor size | 12.7 mm |
| Cutting Capacity | Ø20mm |
| Rotating speed of Wheel | 100-400 rpm adjustable |
| Sample positioning & accuracy | ± 0.01mm Specimen drive arrangement with accuracy not exceeding 10 microns Stainless steel high exactness axle arrangement of 10-20 microns |
| Speed Display | Digital RPM meter |
| Down fed facility with different weight | Up to 400gm |
| Motor | 1 HP |
| Power source | 210-230V AC, Single Phase 50HZ (1+N+E) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Low Speed Precision Cutting Machine
Description
Our BC-150A Automatic Metallographic Abrasive cut-off machine can be used to cut various metal and non-metal materials so as to get the required specimen and observe the metallographic or lithofacies structure. It has built in magnetic filtration recirculation cooling system so as to clear up the chips produced during cutting and to avoid burning the metallographic or lithofacies structure of specimen because of heat generated during cutting operation.
Our Automatic Cut-off machine is floor model rigid, sturdy and designed to cut metallurgical samples to gain optimal results with increased surface finish and quality that too consistently and safely. The Abrasive cutting wheelis connected with motor with the help of pulley and belt mechanism in a chamber separate from the main cutting chamber. The machine is PLC programmable and provides longitudinal sectioning (enhancing us to increase the cutting volume) in Automatic as well as Manual mode of cutting and has movable T-slot work table.
Application
Features
- Powder coated thick MS sheet body duly fabricated for longer life
- Manual Cutting and Automatic Cutting modes can be switched as per requirement
- Large Cutting chamber with Acrylic glass observing window
- Various cutting parameters displayed on high definition LCD touch display
- Programmable control of operation with servo operated X-Y movement of worktable
- Adjustable feed rate with oscillating cutting operation
- Automatic retract at the completion of the cutting cycle
- Recirculation coolant tank with caster wheels and magnetic filter separator
- T-Slot work table for clamping irregular components
- Cutting Speed: 0.1-5mm/min stepless
- Dual LED lights to provide optimum illumination inside the cutting chamber
- Door limit switch to stop the operation in case the door is opened
- Key protected LCD display for safer operation of machine
Specifications
| Model No. | BC-150A |
| Cutting Operation | Automatic & Manual |
| Cutting Capacity | Unto 150mm cross-section |
| Cutting Mode | Y Axis |
| Manual/ Motorized | X, Y, Z all three Axis |
| Cut-Off Wheel Size | 16” (400mm) Bore Dia: 25.4mm, Thickness: 2.5mm |
| Cutting motor Power | 10 HP, 2800 RPM, 415 Volts, 50Hz |
| Abrasive Wheel RPM | 2800 RPM |
| Coolant Motor Power | 0.1 HP,2800 RPM, 415 Volts, 50Hz |
| Coolant Tank | 60 Ltr. Recirculating Coolant tank with Magnetic Separator |
| Cooling | By flexible high flow water jets to provide optimum cooling |
| Table movements | X axis –150mm, Y axis—250mm |
| T-Slot Bed | 250 x 250mm with 8mm T- Nuts |
| Safety Feature | Emergency Stop Switch with Door limit Switch |
| Bed Wash | Will provide high pressure water jet |
| Light in the working area | Dual LED light in the cutting chamber providing safe and clear illumination. |
| Power Supply | 415 Volts, 50 Hz, (3Phase+1Neutral) |
| Dimensions | 1250 x 1050 x 1300mm (Approx.) |
| Weight | 550 Kg. (Approx.) |
|
|
Accessories
Software Description
Download Cataloge
ENQUIRY
Automatic Metallographic Abrasive Cut-Off Machine
Description
Application
It is suitable for cutting precision various materials with strong ability, high reliability, easy operation. The machine consists of machine body, electrical control tank, super cutting room, and cooling system, supporting more economical and convenient cutting models. Meanwhile the user can define cutting models. Meanwhile the user can define cutting speed and track. At the same time, this machine has following features, such as self-test, security. Running tips in order to improve the quality of cutting sample. It is one necessary equipment in laboratory of colleges, research institutes and factories.
Features
Specifications
| Model No. | BACM-6100D |
| Input voltage | 380v/50HZ |
| Feed speed | 0.1-15mm/m |
| Spindle speed | 2200RPM |
| Cut-off wheel | Φ350×2.5×32mm |
| Cutting capacity (Max) | 145mm (Only Y axis for Auto Manu) |
| Max Table Moving Distance | 145mm (Only Y axis for Auto Manu) |
| Input power | 3.3kw |
| Cutting motor | 3kw |
| Dimensions | 960mm×855mm×735mm |
| Table Dimension | 330mm×280mm |
| Net weight | 285kg |
| Optional | Cabinet / Transversal worktable (X axis) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Metallographic Specimen Cutting Machine
Description
Model BETACUT-5000 precise cutting machine is very suitable for non-deforming cutting to the materials such as metal, electronic part, ceramic, crystal, hard alloy, lithofacies sample, mineral sample, concrete, organic material, biological materials etc. This machine can use diamond cutting disc or resin cutting disc, it features wide application, high cutting accuracy, powerful cutting ability and wide speed adjusting range. It is an ideal option for the lab of factories, science and research institutions and universities.
Application
Features
- Equipped with re-circulating & cooling system.
- The feeding speed can be preset (0-180mm/min).
- Menu operation, large touch screen LCD display of various data.
- Wide cutting chamber and work table, long cutting distance.
- Cutting method can be defined by customer freely.
- Ultra-large and closed cutting chamber with safety switch.
Specifications
| Model No. | BETACUT‐5000 |
| Max. cutting diameter | Φ60mm |
| Main shaft rotating speed: | 300~5000rpm adjustable (1 rpm increment) |
| Cutting disc diameters | 200*1*32mm (100mm, 125mm, 150mm optional) |
| Feeding speed | 0~3mm/s (0.01mm/s increment) |
| Withdraw speed of impact cutting | 0~4mm/s |
| Forward distance of impact cutting | 0.1~2mm |
| Withdraw distance of impact cutting | 0~1.99mm |
| Maximum cutting travel | Y-axis 220mm |
| Main shaft Z-axis compensation distance | 25mm |
| Work table size | 350 x 200mm (X axis and Y axis) |
| Servo motor power | 1800 W |
| Power supply | single phase, 220V, 50Hz |
| Net weight | 154Kg |
| Overall dimension | 790 × 650 × 590mm (L × W × H) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Precise Metallographic Specimen Cutting Machine
Description
BCM-200XY high-speed precision cutting machine adopts touch screen and PLC control, with stable performance and real-time display of cutting parameters; Y-axis automatic feed cutting, with high positioning accuracy, large speed range and strong cutting capacity; X-axis automatic feed cutting can make a series of cuts. The cutting chamber adopts a fully enclosed structure with transparent protective cover for observation during cutting; equipped with circulating cooling system, the surface of the cut specimen is bright and flat without burns;
It is especially suitable for precision deformation-free cutting of metals, electronic components, ceramic materials, crystals, hard alloys, rock and ore, concrete, organic materials, biological materials (teeth, bone) and other materials, and is ideal for automatic precision cutting on the table.
Application
Features
Specifications
| Model No. | BCM-200XY |
| Cutting method | Direct cutting, Impact cutting |
| Feed speed | 0.01-5mm/s |
| Manual feed speed | 0-30mm/s |
| Impact cutting distance | 0.1-2mm |
| Cutting wheel size | Φ200x0.9xΦ32mm |
| Spindle speed | 500-5000rpm |
| Y-axis travel | 200mm |
| X-axis travel | 45mm (can extend to 60mm) |
| Maximum cutting diameter | Φ 60mm |
| Servo Motor power | 750W (optional 1.1KW) |
| Input power | Single Phase AC220V，50Hz, 1000W |
| Display and control | Touch Screen |
| Transverse clamping width | 200mm |
| Longitudinal clamping length | 150mm |
| Cutting fixture | Quick Clamp |
| Cutter Size & Net weight | 750×860×430mm (WXDXH); 97kg |
| Cutter pack size & G/W | 935x865x566mm, 120kg |
| Water tank size and N/W | 470x370x300mm, 17kg |
| Water tank Pack size & G/W | 650x440x460mm, 27kg |
Accessories
| Item | Quantity | Quantity | Quantity |
| CM-200Y cutting machine | 1 | Wrench 17#-19# | 1 |
| Live spanner 0-200 | 1 | water tank | 1 |
| Diamond Cutting wheel Φ200mm | 1 | Power line 3*1.5 | 1 |
| Water inlet & Drain-pipe | 2 | Manual & Certificate | 1 |
Software Description
Download Cataloge
ENQUIRY
High-Speed Precision Metallographic Sample Cutting Machine
Description
Our ACO-150A Metallographic specimen cutting machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure.
It has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of heat. This machine features easy operation and reliable safety. It is the necessary specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Large viewing window to monitor the cutting operation.
- Inside chamber is illuminated and see-through hood is provided for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch
- Door Safety Interlock
- Side Opening for Longer Component.
- Easy Operator Panel
- Oscillation: Oscillation is provided for Smooth Cutting.
Specifications
| Model No. | ACO-150A |
| Operation | Manual |
| Cutting Action | Oscillation is Provided For Smooth Cutting. |
| Cutting Capacity | 150mm |
| Cut-Off Wheel Size | 16” (400mm) |
| Cutting motor Power | 5 HP or 7.5HP (As per customer requirement) 3 Phase 415 Volts, 50Hz |
| Abrasive wheel RPM | 2400 RPM Approx. |
| Spindle RPM | 2400 RPM approx. |
| Table Movement | X- Axis – 100mm Y- Axis – 120mm |
| Coolant Motor Power | 0.1 HP – 3 Phase |
| Coolant Tank | 50Ltr. Recirculating Coolant tank inbuilt |
| Vice | Self-Centring 360 rotation opening 6” jaw |
| Safety Feature | Emergency Stop Switch with Door limit Switch |
| Dimensions | 650mm X 800mm X 1450mm |
| Weight | 250 Kg. (approx.) |
Accessories
Software Description
Download Cataloge
ENQUIRY
Metallographic Specimen Cut-Off Machine
Description
Our ACO-150AM Metallographic specimen cutting machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure.
It has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of heat. This machine features easy operation and reliable safety. It is the necessary specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Large viewing window to monitor the cutting operation.
- Inside chamber is illuminated and see-through hood is provided for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch.
- Door Safety Interlock.
- Side Opening for Longer Component.
- Easy Operator Panel.
- Motorized Oscillation is provided for Smooth Cutting.
Specifications
| Model No. | ACO-150AM |
| Operation | Manually by moving motor to the sample. Also, sample can be moved by lead screw |
| Cutting Action | By manual Cut-Off wheel arcs down |
| Cutting Capacity (Max.) | 150 mm |
| Cut-Off Wheel Size (Max.) | 400mm OD x 2.5mm thick x 25.4mm ID |
| Cutting Motor Power | 7.5 H.P. 2800 rpm, 3 Phase, 415 Volts, 50Hz |
| Spindle Speed | 2800 RPM |
| Coolant Motor Pump | 0.1HP (Bharat Bijlee) |
| Cooling Action | Cooling by three high flow water jets to provide optimum cooling |
| Coolant tank | Cooling by three high flow water jets to provide optimum cooling |
| Coolant tank Capacity | 100 Ltr. |
| XY stage movement | Manual |
| Clamping | T SLOT bed & vice 6" to hold irregular objects, gears, shafts (dia. 30- 150 mm, length upto 100 mm), vertical cut of shafts must be feasible, strong grip, easy to clamp |
| Oscillation | Oscillation is Provided For Smooth Cutting |
| Fluorescent light | Fluorescent waterproof light in the working area provides safe and clear illumination |
| Dust Particle collector tank | through Magnetic Separator |
| Safety Feature | Safety Interlocking Door Switch |
| Weight | 320 Kg. (approx.) |
| Dimensions (W x D x H) mm | 900x 1000 x1750mm |
| Additional accessories | Clamping vice,, tool kit for vice adjustment |
Accessories
Software Description
Download Cataloge
ENQUIRY
Metallographic Specimen Cut-Off Machine
Description
Our ACO-200AM Metallographic specimen cutting machine can be used to cut various metal and non-metal materials so as to get specimen and observe the metallographic or lithofacies structure.
It has cooling system so as to clear up the heat produced during cutting and avoid to burn the metallographic or lithofacies structure of specimen because of heat. This machine features easy operation and reliable safety. It is the necessary specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Large viewing window to monitor the cutting operation.
- Inside chamber is illuminated and see-through hood is provided for monitoring the cutting operation.
- Coolant circulation is provided with suitable filtering arrangement.
- Emergency Stop Switch with Door limit Switch.
- Door Safety Interlock.
- Side Opening for Longer Component.
- Easy Operator Panel.
- Motorized Oscillation is provided for Smooth Cutting.
Specifications
| Model No. | ACO-200AM |
| Operation | Manually by moving motor to the sample. Also, sample can be moved by lead screw |
| Cutting Action | By manual Cut-Off wheel arcs down |
| Cutting Capacity (Max.) | 200 mm |
| Cut-Off Wheel Size (Max.) | 500mm / 20" |
| Cutting Motor Power | 15 H.P. (Bharat Bijli) 3 Phase, 415 Volts, 50Hz s |
| Spindle Speed | 2200 RPM |
| Coolant Motor Pump | 0.24 HP, 3 Phase (70LPM) |
| Cooling Action | Cooling by three high flow water jets to provide optimum cooling |
| Fluorescent light | Fluorescent light in the working area provides safe and clear illumination |
| Coolant tank | Recirculation pump & Coolant tank, re-circulation coolant tank |
| Coolant tank Capacity | 100 Ltr. |
| Oscillation | Oscillation is Provided For Smooth Cutting |
| XY stage movement | Manual |
| Vice | 8” Vice with T slot bed for clamping of components |
| Oscillation | Oscillation is Provided For Smooth Cutting |
| Fluorescent light | Fluorescent waterproof light in the working area provides safe and clear illumination |
| Dust Particle collector tank | through Magnetic Separator |
| Safety Feature | Safety Interlocking Door Switch |
| Weight | 900 Kg. (approx) |
| Dimensions (W x D x H) mm | 1100mm x 1650mm x 1970mm |
| Additional accessories | Clamping vice,, tool kit for vice adjustment |
Accessories
Software Description
Download Cataloge
ENQUIRY
Metallographic Specimen Cut-Off Machine
