- Specimen Mounting Press
Description
Our BQ2B Metallographic specimen mounting press is a mechanical type machine. By turning the hand-wheel of the machine, a coupling of bevel gear is rotated to drive the screw rod which in turn pushes/pulls the lower die up and down along the mould sleeve.
The thermoset plastic granules together with specimen being mounted is formed under heated conditions. During this process the pressure is self-adjusted by a spring fixed inside the machine. A signal light is used to indicate the pressure level. The mounting press is equipped with a PID digital temperature controller to establish real-time temperature meanwhile, the timer is equipped to realize the semi-automation of sample – making, while obviously increasing working efficiency.
For each specimen-mounting, 8-10 minutes is enough and a mirror like specimen can be acquired.
Application
Features
Specifications
| Model No. | BQ2B-22 | BQ2B-30 | BQ2B-45 | BQ2B-50 |
| Specimen Pressing Size | Ø22 x 25mm | Ø30 x 25mm | Ø45 x 25mm | Ø50 x 25mm |
| Heater Capacity | 650W 220V | 650W 220V | 650W 220V | 650W 220V |
| Adjustable Temp. Range | 0 – 400°C | 0 – 400°C | 0 – 400°C | 0 – 400°C |
| Power | 220V 50Hz voltage fluctuation less than 15% | |||
| Overall dimensions | 340mm x 270mm x 400mm | |||
| Weight | 25 Kg. (approx.) | |||
Accessories
Software Description
Download Cataloge
ENQUIRY
Manual Mounting Press
Description
ABQ2B-50 This Machine is Automatic Mounting Press for metallographic specimen. It is suitable for all Thermosetting Materials, because of the cooling system. It can automatically finish with the heating temperature, the holding time and acting force. The operator can change 4 specifications patterns according to the difficult specimens It can make 2 specimens at one time.
Application
Features
Specifications
| Model No. | ABQ2B-50 |
| Pattern Specimen | Ø25mm, Ø30mm, Ø40mm, Ø50mm |
| Heater Capacity | 650W, 220V |
| Max. power consumption | 1800W |
| Adjustable Temperature Range | 0-3000C |
| Cooling Method | Water Cooling |
| Air Pressure | 0-2MPa (corresponding preparing pressure intensity: 0-72MPa) |
| Power | 220V, 50Hz, Single Phase |
| Heat preserving time | 0-99mins and 99 Seconds |
| Dimension | 615 × 510 × 500 cm |
| Weight | 110Kg |
Accessories
Software Description
Download Cataloge
ENQUIRY
Automatic Mounting Press
Description
BETAMON-7 Automatic Metallographic Specimen Mounting Press is a kind of advanced full automatic mounting press, the whole process of mounting can be controlled by program, and realized one-key operation for process of mounting, includes heating, pressuring, dwell of pressuring, cooling, release of pressuring, etc. It suits to mount the specimen of metal and rock.
Application
Features
- Pneumatic pressuring to solidify mounting materials (Urea-formaldehyde molding powder or Bakelite powder) through the mounting program.
- Built-in water cooling system, mount molding and cool fleetly.
Specifications
| Model No. | BETAMON-7 |
| Diameter of specimen | Ø22mm, Ø30mm, Ø45mm(choose one) |
| Heater | AC 220V/Single phase, 50Hz, 800W |
| Sampling time | Approx. 10 minutes (Thermosetting material) |
| Heating temperature setting range | 0-200 ºC |
| Cooling temperature setting range | 50-200 ºC |
| Heat preserving time | 1-99min |
| Cooling-down method | Automatic water cooling |
| Loading mode | Pneumatic pressure |
| Pressure of gas source | 0.6-0.7MPa |
| Total power supply | 1000W |
| Dimensions(LxWxH) | 470x400x650mm |
| Net weight | Approx. 30kg |
Accessories
Software Description
Download Cataloge
ENQUIRY
Automatic Mounting Press
Description
Model BXQ-5B automatic metallographic specimen mounting press is a kind of full automatic mounting press, equipped with in-out water cooling system. It is suitable for the hot mounting (thermo-hardening & thermoplastic) for all kinds of materials. After the parameters such as heating temperature, heat preserving time etc. are set up, put the specimen and mounting material into the machine, close the cover and press the start button, then the machine will finish the job automatically. It is not necessary for the operator to be on duty. It is the ideal specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Hydraulic loading of pressure
- Equipped with water cooling system
- According to different requirements of the material, there are four kinds of moulds (Ø25mm, Ø30mm, Ø40mm, Ø50mm) that can be chosen to meet the demands at will.
- Equipped with middle mould. It is available to prepare two pieces of specimens at the same time, the capacity is doubled.
Specifications
| Model No. | BXQ-5B |
| Diameter of specimen | Ø25mm,Ø30mm, Ø40mm, Ø50mm |
| Cooling method | water cooling |
| Heater | 1500W |
| Max. power consumption | 1800W |
| Temperature Setting range | 0-180 ºC |
| Heat preserving time | 0-99m99s |
| Power supply | single phase, 220V, 50Hz |
| Weight | 105Kg |
Accessories
Software Description
Download Cataloge
ENQUIRY
Automatic Metallographic Specimen Mounting Press
Description
This machine is suitable for small or irregular specimen so as to cut the sample and polish the sample and then test spectral detection or hardness.
The digital temperature control instrument can control temperature. After mounting the sample, the machine will stop automatically. It is ideal equipment's for factory, scientific research institution and college universities laboratory.
Application
- This machine is designed for purpose of the last process before polishing.
- It is setting up those small, difficult-to-hold or irregular specimens for metallographic test.
- It can facilitate polishing and watch properly the ideal material structure and measure the hardness of the material by hardness tester.
- The inserts for this machine are limited to thermosetting materials only .
- The punching temperature of different thermosetting materials can be adjusted depending upon the features of materials.
Features
Specifications
| Model No. | BQ2B-T SERIES |
| Display | Touch Screen panel |
| Mould diameter | Ø30mm or Ø45mm |
| Thermoforming ranges | MAX190ºC |
| Timer range | 0-30min |
| heating power | 800W |
| Input voltage | 220V/50HZ |
| Dimensions | 260mm x360mm x450mm |
| Net weight | 35KG |
Accessories
Software Description
Download Cataloge
ENQUIRY
Metallographic Specimen Mounting Machine
Description
This automatic mounting press is used to inlay small specimens, specimens in irregular shapes, or specimens which are not easy to take up, it is the preceding process before grinding and polishing metallurgical or rock specimens. The inlaying operation serves to facilitate the grinding and polishing operations of the specimens and the routine observation of the composition of the material under the metallurgical microscope.
The machine is equipped with built-in water cooling system and it is heated, and intensified with pressure automatically. After the formation of the specimen under pressure, it stops the operation and discharges the pressure also in an automatic way. With another press of the knob, the machine automatically turns up the specimen, which may be taken away. Note: It is only for the hot solid materials (such as urea-formaldehyde molding powder and Bakelite powder) with the temperature automatically regulated and controlled.
It is the ideal specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Equipped with water cooling system
- Touch screen LCD operation
- Automatic mounting process
Specifications
| Model No. | BXQ-2 |
| Mould diameter | Ø30mm or Ø45mm |
| Cooling method | Water cooling |
| Heater | 850W |
| Total power consumption | 1000W |
| Power supply | Single Phase, 220V,50Hz |
| Dimension | 420 x 390 x 460mm |
| Net weight | 55 Kg |
Accessories
Software Description
Download Cataloge
ENQUIRY
Automatic Metallographic Specimen Mounting Press
Description
BECMON-1Q-30 is a kind of pneumatic type automatic mounting press, which is suitable for inlaying micro, hard to handle or irregular metallographic and lithofacies specimens, so as to facilitate cutting, grinding and polishing of specimens, and then observe material structure under metallographic microscope, spectral or measure the hardness of the material by hardness tester. In the process of sample preparation, the machine automatically heats up, pressurizes, cools down to the final automatic pressure relief stop through a series of actions, which realizes the effect of unattended sample preparation, and features the advantages of more humanized, simple operation and high efficiency. It is the ideal sample preparing equipment to be used in factories, researching institutes and college laboratories.
Application
Features
- Equipped with oil separator for clean air.
- Equipped with protective cover for safe sample taking.
- Two specimens can be prepared simultaneously.
Specifications
| Model No. | BECMON-1Q-30 |
| Specimen pressing size | Ø30mm |
| Heating ring | 800W |
| Temperature controlling range (Intelligent) | Room temperature~250 ºC (adjustable) |
| Air source pressure | 0.6-0.8mpa |
| Power supply | AC 220V, 50Hz, Single phase |
| Overall dimensions | 320mm x 350mm x 400mm |
| Weight | 20Kg |
Accessories
Software Description
Download Cataloge
ENQUIRY
Automatic Metallographic Specimen Mounting Press (Pneumatic Type)
Description
Model BXQ-2AS automatic metallographic specimen mounting press is a kind of full automatic mounting press, equipped with double working positions and in-out water cooling system. It is suitable for the hot mounting (thermo-hardening & thermoplastic) for all kinds of materials. After the parameters such as heating temperature, heat preserving time etc. are set up, put the specimen and mounting material into the machine, close the cover and press the start button, then the machine will finish the job automatically. It is not necessary for the operator to be on duty. According to different requirements of the material, there are four kinds of moulds that can be chosen to meet the demands at will. It is the ideal specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Specially designed mould locking cap
- Double working positions which increase the sample preparing capacity
- Touch screen operation, automatic mounting process
- Equipped with water cooling system
Specifications
| Model No. | BXQ-2AS |
| Mould diameter | Ø25mm, Ø30mm, Ø40mm, Ø50mm (choose 2 types at random) |
| Cooling method | Water cooling |
| Heater | 1500W*2 |
| Total power consumption | 3300W |
| Power supply | Single Phase, 220V,50Hz |
| Dimension | 670 x 600 x 510mm |
| Net weight | 95 Kg |
Accessories
Software Description
Download Cataloge
ENQUIRY
Double-Station Automatic Metallographic Specimen Mounting Press
Description
Metallographic specimen mounting press is suitable for the thermo- hardening pressing of the small pressing of the small metallographic specimen which is not idiomorphic or hard to take. After forming, it will be very easy to process the grinding polishing of the specimen and it is also convenient to process measuring of metallographic structure under metallographic microscope.
Application
Features
The machine may work stably under the following working condition:
- The temperature of surrounding medium cannot be less than 10°C and more than 40°C
- The relative humidity of air should be no more than 85% (20°C)
- The voltage fluctuation should be no more than 15%
- There should be no obvious vibration source around
- There should be no current conducting dust, explosive and corrosive air.
Specifications
| Model No. | BETAMON-1 |
| Mould diameter | Ø22mm or Ø30mm or Ø45m |
| Max. Sample height | 40mm |
| Heater | 650W |
| Temperature adjusting range | 100-180°C |
| Power supply | Single phase, 220V,50Hz |
| Dimensions | 33x36x43 cm |
| Net weight | 32KG |
Accessories
Software Description
Download Cataloge
ENQUIRY
Metallographic Specimen Mounting Machine
Description
Automatic metallographic specimen mounting press is a kind of pneumatic and full automatic mounting press, equipped with in-out water cooling system. It is suitable for the hot mounting process of thermohardening & thermoplastic materials. This machine can automatically heat, apply pressure and after sample preparation is finished, it can stop working, release pressure and then push out sample automatically. It is the ideal sample preparing equipment to be used in factories, researching institutes and college laboratories.
Application
Features
- Simple structure, quick sample preparation
- Pneumatic pressure applying & releasing
- Automatic sample preparing, automatic sample pushing out
- Touch screen operation
- Cooling method: water cooling
- Three kinds of moulds of Ø22mm, Ø30mm, Ø45mm can be chosen at will
Specifications
| Model No. | BUTOMON-1 |
| Diameter of specimen | Ø22mm, Ø30mm or Ø45mm |
| Heater | 1200W |
| Sample Preparation Time | 10-15 mins |
| Temperature setting range | 0-200 ºC |
| Power supply | Single phase, 220V, 50Hz |
| Dimensions | 380 x 350 x 420 mm |
| Net weight | 50 KG |
Accessories
Optional Accessory:
Pneumatic source: air compressor
Software Description
Download Cataloge
ENQUIRY
Fully Automatic Metallographic Specimen Mounting Press
Description
Model BETAMON-2A automatic metallographic specimen mounting press is a kind of fully automatic mounting press, equipped with in-out water cooling system. It is suitable for the hot mounting (thermo-hardening & thermoplastic) for all kinds of materials. After the parameters such as heating temperature, heat preserving time etc. are set up, put the specimen and mounting material into the machine, close the cover and press the start button, then the machine will finish the job automatically. It is not necessary for the operator to be on duty. It is the ideal specimen preparing instrument for using in factories, scientific research institutes and laboratories of colleges.
Application
Features
- Quick sample preparation within 5 minutes
- 10 groups of data storage
- Electro-hydraulic pressure loading method
- Touch screen operation
- Equipped with water cooling system
Specifications
| Model | BETAMON-2A |
| Mould diameter | Ø22mm or Ø30mm or Ø45mm (choose 1 from 3) |
| Sample preparing pressure | 0-10 MPa |
| Sample preparation time | 5-6 minutes |
| Temperature adjusting range | 10-300 ºC |
| Data storage | 10 groups |
| Heater | 1600W (22mm, 30mm), 2000W (45mm) |
| Power supply | single phase, 220V, 50Hz |
| Dimensions | 61 × 44 × 43 cm |
| Net weight | 45 KG |
Accessories
Software Description
Download Cataloge
ENQUIRY
Automatic Metallographic Specimen Mounting Press
Description
Our transparent moulding machine is suitable for the sample preparation of metallographic cold mounting, and better for epoxy or acrylic cold mounting.
Application
Features
- No electricity, pressurized by a pneumatic system
- With water-separator and fast-insert connectors
- Quick lock and release cover design.
- High performance in sealing, and overflow valve in safety.
- More spacious mounting chamber, and stainless-steel container.
- Equipped with a timer to remind curing time
Specifications
| Model No. | BTM-P |
| Operating Pressure | 2.0 bar |
| Safety Valve Overflow Pressure | 2.8 ~ 3.3. bar |
| Air Pressure Inlet Pressure | 3~10 bar |
| Chamber Diameter | Φ235×170mm |
| Size (W x D x H) in mm | 340 x 400 x 270 (Closed) |
| 340 x 400 x 370 (Open) | |
| Weight | Approx. 8.5 Kg |
Accessories
Software Description
Download Cataloge
ENQUIRY
Pressure Cold Mounting Machine
