Description

Computerized Vickers Hardness tester has a C type load frame. The job is positioned on the test table and lifted by the hand wheel to set focal point. Required load is applied on the job and removed by motorized system. After indexing the plate , optics will come in place of indentation & will transfer the image of indentation to Camera. The image is further digitalized and processed by PC/ TPC for measurement. The diagonal / diameter of the image can be measured automatically / semi automatically / manually to get Vickers Hardness value.

Application

Features

Fully computerized system for indentation measurement and display.
Accurate measurement of Vickers Hardness through matched Optics, CCD Camera, hardware and software using advanced image processing technologies.
Wide range of testing
High accuracy & confirms to related to IS & ISO standard
Windows based software system.
Three modes of measurement, manual, semi auto and auto
In auto mode the image is scanned for measurement and hardness is displayed automatically.
In Semi automatic mode curser is to click on the indentation to get the hardness value.
In manual mode curser is to be matched to the diagonal / diameter of the indentation to get the

Specifications

Model No.	BTV-50-PC
Loads (Kgf.)	5, 10, 20, 30 & 50
Maximum Test height (mm)	200
Depth of Throat (mm)	150
Weight Approx. (Kgf)	180
Dimension L x W x H mm	660 x 180 x 850 mm
Connected load	0.1 KVA, 1 Phase AC, 220V, 50 Hz

Accessories

Flat Table of 100mm Dia
Vee Table for Specimen- 6 to 80 mm Dia
Vickers Diamond Indenter
Vickers test block
Electrical Cord
Instruction Manual

Software Description

Download Cataloge

Click Here For Brochure

ENQUIRY

BTV-50- PC
Computerized Vickers Hardness Tester

Description

Application

Features

Table Top sturdy Model
Front projection screen with Micrometer with Optical system List Count of 0.0005 mm
Motorised Loading & Unloading of Loads
Load selection By Indexible Load Selection Knob
Very wide testing range from very soft Metals to Very Hard Metals
Models with minimum 1 Kg Load are available
The illumination light goes off during the application of Load which reduces the operator's fatigue due to continuous light illumination as well as increases Bulb life
State of Art Load Damping system for a very smooth & Jerk free Loading & unloading of applied Load
Machine Confirms to IS: 1754-2002 for Vickers & IS: 2281-2005 / BS240 for Brinell.

Specifications

Model No.	BTV-50	BTV-50-S
Test Loads (Kgf)	5, 10, 20, 30 & 50	1, 5, 10, 20, 30 & 50
Maximum Test height (mm)	200 mm
Depth of throat (mm)	150 mm
Weight Approx. (Kgf)	180
Dimension L x W x H mm	660x180x85mm
Connected Load	0.1 KVA, 1 Phase AC, 220V, 50 Hz

Accessories

Flat Table of 100mm Dia
Vee Table for Specimen: 6 to 80 mm Dia
Vickers Diamond Indenter
Vickers test block
Electrical Cord
Instruction Manual

Software Description

Download Cataloge

Click Here For Brochure

ENQUIRY

BTV-50/50-S
Vickers Hardness Tester

BVH-10ALT
Advanced Touch Screen Digital Vickers Hardness Tester

BVH-30ALT
Advanced Touch Screen Digital Vickers Hardness Tester

BVH-50ALT
Advanced Touch Screen Digital Vickers Hardness Tester

Description

Application

Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
Glass, chip and ceramic material.

Features

The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
Industrial digital screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process;
Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Model No.	BVH-10DA	BVH-10DM
Turret	Automatic	Manual
Hardness Scale & Test Force	HV0.5, HV1, HV3, HV5, HV10 0.5kg (4.9N), 1kg (9.8N), 3kg (29.4N), 5kg (49N), 10kg (98N)
Hardness conversion scale	HRA, HRB, HRC, HRD, HK, HBS, H15N, H30N, H45N, H15T, H30T, H45T
Loading speed	≤50μm/sec
Min. Measuring Unit	0.02μm
Indenter	Standard Rectangular pyramid diamond indenter (136º±0.5º)
Hardness Value Range	5-3000HV, 8-4500HK
Hardness Value of Reading	Digital LCD Screen
Total Magnification	100X (For Observation), 200X (For Measurement)
Loading Method	Automatically (Load, dwell and unload)
Dwell Time	1-99s (each step is 1 second)
Maximum Height	175mm
Throat depth	135mm
Light Source	LED Cold light source
Power Supply	220V + 5%, 50/60 Hz (110V is available)
X-Y Testing Table (optional purchase)	Dim.: 100×100 mm, Max. Travel Range: 25×25mm, Moving Resolution Ratio: 0.01mm
Instrument size and Net weight	600220700mm; 55kg
Executed Standard	GB/T4340, ASTM E384 & E92, EN-ISO 6507-2, JIS B-7734
Optional Purchase Accessories	Image analysis software; Metallographic equipment; Knoop Indenter; hardness block; 15X micrometer eyepiece.

Accessories

10X electronic eyepiece : 1pc
10X and 20X objective lens : 1pc
Vickers indenter : 1pc
Level bubble : 1pc
Large / Medium / V-shape Testing Table : 1pc
Power line : 1pc
Dust proof cover : 1pc
Manual Book : 1pc
Hardness Conversion Tables : 1pc
Quality certificate : 1pc
Warranty Card : 1pc
Accessory case : 1pc
Standard block of hardness : 2pcs
horizontal adjusting screw : 4pcs

Software Description

Download Cataloge

Click Here For Brochure

ENQUIRY

BVH-10DA/10DM
Digital Vickers Hardness Tester

BVH-10BA/10BM
Advanced Digital Vickers Hardness Tester

BVH-30BA/30BM
Advanced Digital Vickers Hardness Tester

BVH-50BA/50BM
Advanced Digital Vickers Hardness Tester

BVH-10AT-8P/10MT-8P
Advanced Digital Vickers Hardness Tester

BVH-30AT-8P/30MT-8P
Advanced Digital Vickers Hardness Tester

BVH-50AT-8P/50MT-8P
Advanced Digital Vickers Hardness Tester

BVH-10AT-8/10MT-8
Touch Screen Digital Vickers Hardness Tester

BVH-30AT-8/30MT-8
Touch Screen Digital Vickers Hardness Tester

BVH-50AT-8/50MT-8
Touch Screen Digital Vickers Hardness Tester

BVH-10A/10M
Automatic/Manual Turret Vickers Hardness Tester

BVH-30A/30M
Automatic/Manual Turret Vickers Hardness Tester

BVH-50A/50M
Automatic/Manual Turret Vickers Hardness Tester

BVH-10AT/10MT
Advanced Digital Vickers Hardness Tester With Touch Screen Control

BVH-30AT/30MT
Advanced Digital Vickers Hardness Tester With Touch Screen Control

BVH-50AT/50MT
Advanced Digital Vickers Hardness Tester With Touch Screen Control

Description

Application

Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
Glass, chip and ceramic material.

Features

The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
Industrial digital screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process;
Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Model No.	BVH-30DA	BVH-30DM
Turret	Automatic	Manual
Hardness Scale & Test Force	HV1, HV3, HV5, HV10, HV20, HV30 1kg(9.8N),3kg(29.4N),5kg(49N),10kg(98N),20kg(196N), 30kg(294N)
Hardness conversion scale	HRA, HRB, HRC, HRD, HK, HBS, H15N, H30N, H45N, H15T, H30T, H45T
Loading speed	≤50μm/sec
Min. Measuring Unit	0.02μm
Indenter	Standard Rectangular pyramid diamond indenter (136º±0.5º)
Hardness Value Range	5-3000HV, 8-4500HK
Hardness Value of Reading	Digital LCD Screen
Total Magnification	100X (For Observation), 200X (For Measurement)
Loading Method	Automatically (Load, dwell and unload)
Dwell Time	1-99s (each step is 1 second)
Maximum Height	175mm
Throat depth	135mm
Light Source	LED Cold light source
Power Supply	220V + 5%, 50/60 Hz (110V is available)
X-Y Testing Table (optional purchase)	Dim.: 100×100 mm, Max. Travel Range: 25×25mm, Moving Resolution Ratio: 0.01mm
Instrument size and Net weight	600220700mm; 55kg
Executed Standard	GB/T4340, ASTM E384 & E92, EN-ISO 6507-2, JIS B-7734
Optional Purchase Accessories	Image analysis software; Metallographic equipment; Knoop Indenter; hardness block; 15X micrometer eyepiece

Accessories

10X electronic eyepiece : 1pc
10X and 20X objective lens : 1pc
Vickers indenter : 1pc
Level bubble : 1pc
Large / Medium / V-shape Testing Table : 1pc
Power line : 1pc
Dust proof cover : 1pc
Manual Book : 1pc
Hardness Conversion Tables : 1pc
Quality certificate : 1pc
Warranty Card : 1pc
Accessory case : 1pc
Standard block of hardness : 2pcs
horizontal adjusting screw : 4pcs

Software Description

Download Cataloge

Click Here For Brochure

ENQUIRY

BVH-30DA/30DM
Digital Vickers Hardness Tester

Description

Application

Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
Glass, chip and ceramic material.

Features

The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
Industrial digital screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process;
Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Model No.	BVH-50DA	BVH-50DM
Turret	Automatic	Manual
Hardness Scale & Test Force	HV1, HV5, HV10, HV20, HV30, HV50 1kg(9.8N), 5kg(49N), 10kg(98N), 20kg(196N), 30kg(294N), 50kg(490N)
Hardness conversion scale	HRA, HRB, HRC, HRD, HK, HBS, H15N, H30N, H45N, H15T, H30T, H45T
Loading speed	≤50μm/sec
Min. Measuring Unit	0.02μm
Indenter	Standard Rectangular pyramid diamond indenter (136º±0.5º)
Hardness Value Range	5-3000HV, 8-4500HK
Hardness Value of Reading	Digital LCD Screen
Total Magnification	100X (For Observation), 200X (For Measurement)
Loading Method	Automatically (Load, dwell and unload)
Dwell Time	1-99s (each step is 1 second)
Maximum Height	175mm
Throat depth	135mm
Light Source	LED Cold light source
Power Supply	220V + 5%, 50/60 Hz (110V is available)
X-Y Testing Table (optional purchase)	Dim.: 100×100 mm, Max. Travel Range: 25×25mm, Moving Resolution Ratio: 0.01mm
Instrument size and Net weight	600220700mm; 55kg
Executed Standard	GB/T4340, ASTM E384 & E92, EN-ISO 6507-2, JIS B-7734
Optional Purchase Accessories	Image analysis software; Metallographic equipment; Knoop Indenter; hardness block; 15X micrometer eyepiece

Accessories

10X electronic eyepiece : 1pc
10X and 20X objective lens : 1pc
Vickers indenter : 1pc
Level bubble : 1pc
Large / Medium / V-shape Testing Table : 1pc
Power line : 1pc
Dust proof cover : 1pc
Manual Book : 1pc
Hardness Conversion Tables : 1pc
Quality certificate : 1pc
Warranty Card : 1pc
Accessory case : 1pc
Standard block of hardness : 2pcs
horizontal adjusting screw : 4pcs

Software Description

Download Cataloge

Click Here For Brochure

ENQUIRY

BVH-50DA/50DM
Digital Vickers Hardness Tester

Description

Automatic loading - dwell - unloading
Precise manual analog eyepiece 10X
Reserved CCD camera path, can work with camera and hardness software system
High resolution optical system, indentation image very clear
One time casting shell with car painting
Touch screen with menu structure, easy operate
LED light source, service time more longer

Application

Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
Glass, chip and ceramic material.

Features

The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
Large size touch screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process.
Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Model no.	BVH-10ZT	BVH-10T
Turret	Automatic	Manual
Hardness Scale	HV0.3, HV0.5, HV1, HV3, HV5, HV10
Test Force	0.3kg(2.94N), 0.5kg (4.9N), 1kg (9.8N), 3kg (29.4N), 5kg (49N), 10kg (98N)
Hardness conversion scale	HRA, HRB, HRC, HRD, HK, HBS, H15N, H30N, H45N, H15T, H30T, H45T
Loading speed	≤50μm/sec
Min. Measuring Unit of eyepiece reading drum	0.5μm
Indenter	Standard Rectangular pyramid diamond indenter (136º±0.5º)
Hardness Value Range	5-3000HV, 8-4500HK
Data Display	Touch screen
Total Magnification	100X (For Observation), 200X (For Measurement)
Loading Method	Automatically (Load, dwell and unload)
Dwell Time	1-99s (each step is 1 second)
Maximum Height	175mm
Throat depth	135mm
Light Source	LED Cold light source
Power Supply	220V + 5%, 50/60 Hz (110V is available)
X-Y Testing Table (optional purchase)	Dim.: 100×100 mm, Max. Travel Range: 25×25mm, Moving Resolution Ratio: 0.01mm
Instrument size	600220700mm
Net weight	55kg
Executed Standard	GB/T4340, ASTM E384 & E92, EN-ISO 6507-2, JIS B-7734

Accessories

10X analog eyepiece : 1 pc
Power line : 1 pc
10X and 20X objective lens : 1 pc
Dust proof cover : 1 pc
Vickers indenter : 1 pc
Hardness Conversion Tables : 1 pc
Level bubble : 1 pc
Quality certificate : 1 pc
Large / Medium / V-shape Testing Table : 1 pc
Warranty Card : 1 pc
horizontal adjusting screw : 4 pcs
Standard block of hardness : 2 pcs
Accessory case : 1 pc
Manual Book : 1 pc

Optional Purchase Accessories:

Image analysis software
Metallographic equipment
Knoop Indenter
hardness block
15X micrometer eyepiece

Software Description

Software support automatic measurement & manual measurement, can generate test report automatically in word/Excel format, including hardness value, test force, indentation image and hardness curve, etc.

Software can control the machine turret and generate test report including hardness value curve (Via RS232 port). Software install on the computer, connect with hardness tester through RS232 port. All the testing result can save to computer and generate test report in word format.

Download Cataloge

Click Here For Brochure

ENQUIRY

BVH-10ZT/10T
Vickers Hardness Tester With Touch Screen Control

Description

Automatic loading - dwell - unloading
Precise manual analog eyepiece 10X
Reserved CCD camera path, can work with camera and hardness software system
High resolution optical system, indentation image very clear
One time casting shell with car painting
Touch screen with menu structure, easy operate
LED light source, service time more longer

Application

Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
Glass, chip and ceramic material.

Features

The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
Large size touch screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process.
Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Model no.	BVH-30ZT	BVH-30T
Turret	Automatic	Manual
Hardness Scale	HV1, HV3, HV5, HV10, HV20, HV30
Test Force	1kg(9.8N), 3kg(29.4N), 5kg(49N),10kg(98N), 20kg(196N), 30kg(294N)
Hardness conversion scale	HRA, HRB, HRC, HRD, HK, HBS, H15N, H30N, H45N, H15T, H30T, H45T
Loading speed	≤50μm/sec
Min. Measuring Unit of eyepiece reading drum	0.5μm
Indenter	Standard Rectangular pyramid diamond indenter (136º±0.5º)
Hardness Value Range	5-3000HV, 8-4500HK
Data Display	Touch screen
Total Magnification	100X (For Observation), 200X (For Measurement)
Loading Method	Automatically (Load, dwell and unload)
Dwell Time	1-99s (each step is 1 second)
Maximum Height	175mm
Throat depth	135mm
Light Source	LED Cold light source
Power Supply	220V + 5%, 50/60 Hz (110V is available)
X-Y Testing Table (optional purchase)	Dim.: 100×100 mm, Max. Travel Range: 25×25mm, Moving Resolution Ratio: 0.01mm
Instrument size	600220700mm
Net weight	55kg
Executed Standard	GB/T4340, ASTM E384 & E92, EN-ISO 6507-2, JIS B-7734

Accessories

10X analog eyepiece : 1 pc
Power line : 1 pc
10X and 20X objective lens : 1 pc
Dust proof cover : 1 pc
Vickers indenter : 1 pc
Hardness Conversion Tables : 1 pc
Level bubble : 1 pc
Quality certificate : 1 pc
Large / Medium / V-shape Testing Table : 1 pc
Warranty Card : 1 pc
horizontal adjusting screw : 4 pcs
Standard block of hardness : 2 pcs
Accessory case : 1 pc
Manual Book : 1 pc

Optional Purchase Accessories:

Image analysis software
Metallographic equipment
Knoop Indenter
hardness block
15X micrometer eyepiece

Software Description

Software support automatic measurement & manual measurement, can generate test report automatically in word/Excel format, including hardness value, test force, indentation image and hardness curve, etc.

Software can control the machine turret and generate test report including hardness value curve (Via RS232 port). Software install on the computer, connect with hardness tester through RS232 port. All the testing result can save to computer and generate test report in word format.

Download Cataloge

Click Here For Brochure

ENQUIRY

BVH-30ZT/30T
Vickers Hardness Tester With Touch Screen Control

Description

Automatic loading - dwell - unloading
Precise manual analog eyepiece 10X
Reserved CCD camera path, can work with camera and hardness software system
High resolution optical system, indentation image very clear
One time casting shell with car painting
Touch screen with menu structure, easy operate
LED light source, service time more longer

Application

Steel, nonferrous metals, tinsel, cemented carbide, sheet metal, metallographic structure.
Carburization, nitriding and decarburization layer, surface hardening layer, galvanized coating, coating.
Glass, chip and ceramic material.

Features

The optical system designed by our senior optical engineer not only meet the definition of hardness testing requirements, but also can observe the micro structure of the material, image is very clear.
According to different visual habits of the operators, the strength of the light source can be adjusted. To avoid the visual fatigue for long time operation.
With Vickers hardness and Knoop hardness testing capabilities. By measuring the indentation diagonal length, the hardness value will show on the screen directly, no need to check hardness table.
Large size touch screen can direct display hardness value, conversion hardness, testing method, testing force, dwell time, testing times and testing process.
Reserved CCD camera optical path, support machine work with computer and hardness measuring software system.

Specifications

Model no.	BVH-50ZT	BVH-50T
Turret	Automatic	Manual
Hardness Scale	HV1, HV5, HV10, HV20, HV30, HV50
Test Force	1kg(9.8N), 5kg(49N), 10kg(98N), 20kg(196N), 30kg(294N), 50kg(490N)
Hardness conversion scale	HRA, HRB, HRC, HRD, HK, HBS, H15N, H30N, H45N, H15T, H30T, H45T
Loading speed	≤50μm/sec
Min. Measuring Unit of eyepiece reading drum	0.5μm
Indenter	Standard Rectangular pyramid diamond indenter (136º±0.5º)
Hardness Value Range	5-3000HV, 8-4500HK
Data Display	Touch screen
Total Magnification	100X (For Observation), 200X (For Measurement)
Loading Method	Automatically (Load, dwell and unload)
Dwell Time	1-99s (each step is 1 second)
Maximum Height	175mm
Throat depth	135mm
Light Source	LED Cold light source
Power Supply	220V + 5%, 50/60 Hz (110V is available)
X-Y Testing Table (optional purchase)	Dim.: 100×100 mm, Max. Travel Range: 25×25mm, Moving Resolution Ratio: 0.01mm
Instrument size	600220700mm
Net weight	55kg
Executed Standard	GB/T4340, ASTM E384 & E92, EN-ISO 6507-2, JIS B-7734

Accessories

10X analog eyepiece : 1 pc
Power line : 1 pc
10X and 20X objective lens : 1 pc
Dust proof cover : 1 pc
Vickers indenter : 1 pc
Hardness Conversion Tables : 1 pc
Level bubble : 1 pc
Quality certificate : 1 pc
Large / Medium / V-shape Testing Table : 1 pc
Warranty Card : 1 pc
horizontal adjusting screw : 4 pcs
Standard block of hardness : 2 pcs
Accessory case : 1 pc
Manual Book : 1 pc

Optional Purchase Accessories:

Image analysis software
Metallographic equipment
Knoop Indenter
hardness block
15X micrometer eyepiece

Software Description

Software support automatic measurement & manual measurement, can generate test report automatically in word/Excel format, including hardness value, test force, indentation image and hardness curve, etc.

Software can control the machine turret and generate test report including hardness value curve (Via RS232 port). Software install on the computer, connect with hardness tester through RS232 port. All the testing result can save to computer and generate test report in word format.

Download Cataloge

Click Here For Brochure

ENQUIRY

BVH-50ZT/50T
Vickers Hardness Tester With Touch Screen Control

Categories

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

Enter the code shown in the image below

CONTACT INFO

QUICK LINKS

NEWSLETTER SUBSCRIBE
